CMP10

Rated AES (W)

300

Program (W)

600

Peak (W)

1200

Frequency Range (Hz)

78 - 22000 Hz

Sensitivity (dB)

97 dB (1W/1m)

Max SPL (dB)

128 dB

Dispersion

80° conical

Impedance (Ohm)

8 ohms

Crossover (Hz)

1500 Hz

LF Driver

1 x woofer 10" with ferrit magnet

HF Driver

1 x annular compression driver 1" with neodymium magnet

Voice Coil (LF)

2.5"

Voice Coil (HF)

1.75"

Basket Material

aluminum

Diaphragm Material

PEEK (H.T. polymer)

Loudspeaker Type

Coaxial speaker; compact cabinet speaker

Enclosure

Vented

Rigging Points

7 x M8 thread

Connection

2 x 4-pol SpeakON mounting version (F)

Driver Brand

CELTO ACOUSTIQUE driver Built with NEUTRIK connector

Cabinet Material

Birch multiplex

Finish

Black, rubberized Polyurea coating

Width (cm)

44

Height (cm)

30.6

Depth (cm)

29.8

Weight (kg)

15.00

Controls

Mode switch (1+1- / 2+2-)
