CT12V

Rated AES (W)

500

Program (W)

1000

Peak (W)

2000

Frequency Range (Hz)

52 - 22000 Hz

Sensitivity (dB)

97 dB (1W/1m)

Max SPL (dB)

130 dB

Dispersion

80° x 50° rotatable horn

Impedance (Ohm)

8 ohms

Crossover (Hz)

Passive 1600 Hz

LF Driver

1 x woofer 12"

HF Driver

1 x annular compression driver 1"

Voice Coil (LF)

3"

Voice Coil (HF)

1.75"

Basket Material

aluminum

Diaphragm Material

PEEK (H.T. polymer)

Loudspeaker Type

Compact cabinet speaker

Enclosure

Vented

Mounting System

Dual flange: Ø 35mm (0° / 10°)

Rigging Points

11 x M8 thread

Connection

2 x 4-pol SpeakON mounting version (F)

Driver Brand

CELTO ACOUSTIQUE driver Built with NEUTRIK connector

Cabinet Material

Birch multiplex

Finish

Black, textured coating, painted

Width (cm)

62

Height (cm)

35.6

Depth (cm)

34.5

Weight (kg)

20.60
