CELTO ACOUSTIQUE
CT15V
2-way fullrange loudspeaker
Technical Specifications
Rated AES (W)
500
Program (W)
1000
Peak (W)
2000
Frequency Range (Hz)
50 - 22000 Hz
Sensitivity (dB)
98 dB (1W/1m)
Max SPL (dB)
131 dB
Dispersion
80° x 50° rotatable horn
Impedance (Ohm)
8 ohms
Crossover (Hz)
Passive 1600 Hz
LF Driver
1 x woofer 15"
HF Driver
1 x annular compression driver 1"
Voice Coil (LF)
3.5"
Voice Coil (HF)
1.75"
Basket Material
aluminum
Diaphragm Material
PEEK (H.T. polymer)
Loudspeaker Type
Compact cabinet speaker
Enclosure
Vented
Mounting System
Dual flange: Ø 35mm (0° / 10°)
Rigging Points
11 x M8 thread
Connection
2 x 4-pol SpeakON mounting version (F)
Driver Brand
CELTO ACOUSTIQUE driver Built with NEUTRIK connector
Cabinet Material
Birch multiplex
Finish
Black, textured coating, painted
Width (cm)
44.5
Height (cm)
71.0
Depth (cm)
41.4
Weight (kg)
26.65
