iFIX17S G2

Rated AES (W)

1000

Program (W)

2000

Peak (W)

4000

Frequency Range (Hz)

38 - 1200

Sensitivity (dB)

99

Max SPL (dB)

135

Dispersion

Omnidirectional

Impedance (Ohm)

8

Crossover Mode

Active only

Recommended Setup

High-pass 30 Hz, 24 dB/oct. Low-pass 120 Hz, 24 dB/oct.

LF Driver

1 x 18" ferrite woofer

Voice Coil (LF)

3.5"

Basket Material

Aluminium

Loudspeaker Type

Subwoofer

Enclosure

Bass reflex

Rigging Points

8 x M8 threaded points

Connection

Input: speaker via screw terminal

Cabinet Material

Birch multiplex wood, 18 mm

Finish

Black / White / Natural White

Width (cm)

59.6

Height (cm)

48.2

Depth (cm)

60

Weight (kg)

29.5
