iFIX7 G2

Rated AES (W)

200

Program (W)

400

Peak (W)

800

Frequency Range (Hz)

52 - 22000

Sensitivity (dB)

92 (1W/1m)

Max SPL (dB)

121

Dispersion

80° conical

Impedance (Ohm)

8

Crossover (Hz)

Passive 2400

Recommended Setup

High-pass 30 Hz, 24 dB/oct (fullrange). High-pass 60-140 Hz with iFIX13S/iFIX17S subwoofer.

LF Driver

1 x 8" ferrite woofer

HF Driver

1 x 1" compression driver

Voice Coil (LF)

2"

Voice Coil (HF)

1"

Basket Material

Aluminium

Diaphragm Material

Polyimide

Loudspeaker Type

Coaxial; surface-mount (wall/ceiling)

Enclosure

Bass reflex

Mounting System

Mounting bracket

Connection

Input: speaker via screw terminal

Driver Brand

CELTO ACOUSTIQUE

Cabinet Material

Birch multiplex wood, 15 mm

Finish

Black / White / Natural White

Width (cm)

37

Height (cm)

24.6

Depth (cm)

26.8

Weight (kg)

10
